HFPV-600 Hydraulic Crawler DTH Drilling Rig

Drilling Diameter: 90-400mm
Drilling Depth:20-120m
Engine Power:92kW
Rotary speed:0-110r/min

product Introduction

HFPV-600 hydraulic crawler drill rig, using new type of hydraulic technology, low consumption, large rotary torque, convenient hole deflection. The drilling machine structure is compact, while the mast has adjustable compensation function.

Application

HF385Y drilling rig has reliable performance, high efficiency, suitable for operating conditions. It also reduce costs and improve the efficiency. The drilling rig is mainly used for piling anchor, water wells, photovoltaic solar spiral pile, DTH blasting construction, etc.

TECHNICAL DATA

Bore diameter(hammer) 90-400mm Bore depth 20-120m
Air consumption 10-26m³/min Air pressure 0.7-1.6Mpa (medium)1.6-2.46Mpa (high)
Pipe diameter 76mm/89mm/102mm For rock F=6-20
Bore diameter(screw) Max 400mm Bore depth 0-30m
Screw pipe diameter 130-400mm Once promotion 3200mm
Skid pitch 120º Swinging angle of drilling boom Left and right total 50º
Swinging angle of skid Left and right total 40º Rotation speed 0-110r/min
Host power 92Kw Climb ability 35º
Dimension(L*W*H) 5300*1970*2620mm Weight 5800kg
